Ratchet Binder

Ratchet Binders
A ratchet binder uses two types of simple machines and has two tension hooks on each end and handle. The handle again serves as a lever plus there is the screw thread. Having both simple machines can multiply the force manually applied to the lashing chain assembly.

When using a ratchet binder, the lever and screw work together and increase the force manually applied to the lashing chain assembly. The result is that it takes much less pulling force on the handle to apply tension than you would need with a lever binder.
Ratchets also allow for slower, steadier loading and unloading of forces. This reduces any undue stress or strain on your body. Since ratchet binders are designed with a gear, handle, pawl and end fittings, they will not store up as much energy in the handle as a lever binder will.

Another advantage of ratchet binders is that take-up of the chain is safer. The take-up distance of a ratchet binder is typically eight to ten inches – twice that of a lever binder. While take up with a ratchet binder may take a few extra minutes, it is more controlled and ultimately a safer process.

• Continuous take-up features with infinite adjustment.
• One piece assembly, no bolts and nuts to loosen. Ratchet spring rust proofed.
• All load bearing or holding parts forged.
• Eye bolts and hooks are alloy steel, quenched and tempered.
• Easy to operate-positive ratchet.
